Hy-Pave Dura porous cellular pavers are strong, interlocking, plastic tiles used to create permeable reinforced grassed or gravel areas for a variety of applications. Each plastic tile is made from 100% recycled HDPE and has a low carbon footprint.

Hy-Pave Dura

Hy-Pave Dura porous cellular pavers are a cost effective solution to worn and rutted grassed areas, displaced gravel and for source control of surface water run-off.

The strong, interlocking, plastic tiles create permeable, reinforced surfaces for a variety of applications, offering a environmentally friendly alternative to tarmac or concrete blocks. Each plastic tile is made from 100% recycled HDPE and has a low carbon footprint.

The main benefit over traditional surfaces is the permeability which allows the surface water to drain through the tiles down to the water table - making them fully compliant with Sustainable Urban Drainage Systems (SUDS) and the Flood and Water Management Act 2010 which encourage the use of permeable surfaces to mitigate against flooding in built up areas.

Hy-Pave Dura can be filled with soil and seeded, as the cell structure and open base is designed to promote unrestricted grass root growth to create a naturally growing grass surface that is stabilised and reinforced to withstand frequent trafficking.

Alternatively, the tiles can be filled with gravel, as the cells effectively retain the loose fill to prevent loss or displacement, whilst also preventing rutting (making them ideal for wheel chair access).

Applications

  • Car and coach parks (Grass or gravel)
  • Overspill/overflow grass car parks
  • Emergency services (Fire access routes)
  • HGV service access routes
  • Aircraft taxiways & helipads
  • Walkways and disabled access routes (Disability Discrimination Act 1995)
  • Golf buggy paths
  • Driveways and residential lawn parking
  • SUDS source control
  • Shed foundation/base
Feature Hy-Pave Dura
Tile Size: 500mm x 500mm x 40mm (4 tiles/m²)
Tile Weight: 1.28kg
Wall Thickness: 3mm
Maximum Load: 160 tonnes/m²
Maximum Axle Load: 20 tonnes
Colour: Black (other colours available subject to order quantity)
Working Temperature: HDPE = -20 to +80ºC, PP = -20 to +70ºC
Fire Rating: HB tested to BS EN 11925-2 2010
Material: Recycled or virgin UV stabilised polyethylene/polypropylene (HDPE standard), chemically inert and non-toxic, frost resistant
Pallet Quantity max 60m² per pallet

Features/Benefits

  • Load bearing capacity up to 160 tonnes/m²
  • Vehicle compression strength of 20 tonnes axle loading (meets DIN 1072 standard).
  • Manufactured from recycled polymer which is chemically inert and non-toxic
  • Easily cut with hand or power saw
  • High open area to maximise visual appeal of finished surface
  • Pavers filled with grass or gravel are SUDS source control compliant
  • Choice of colours for marker pegs bays and signage
  • Pre-assembled in 1 m² panels for quick installation
  • 3mm wall thickness for reliable performance
  • Designed to resist lateral movement, improve traction and allow expansion and contraction
  • Promotes optimum grass growth, root protection and surface stabilisation.
  • The open cell structure provides environmentally friendly high surface water infiltration
  • Offers a naturally pleasing appearance
  • Made in the UK
  • Made from 100% Recycled HDPE
  • Low Carbon Footprint
